IN-LITE Ace Up/Down 12v Wall Light - Dark Grey

IN-LITE Ace Up/Down 12v Wall Light - Dark Grey

£182.00
Delivery Time: 1–3 Working Days (in stock) or 3-5 Weeks (out of stock) - Check Availability

Notify me when back in stock

IN-LITE ACE Up-Down Outdoor LED Wall Light

The in-lite ACE Up-Down Wall Light is a stylish, low-voltage outdoor wall light that casts beams both upwards and downwards. With its contemporary dark grey finish, this fixture is perfect for modern gardens, patios, pathways and exterior living spaces.

Designed with recessed LED sources to minimise glare, the ACE Up-Down delivers focused illumination that highlights textures and creates depth in your outdoor lighting scheme. Accessories like the SHUTTER and LENS can be added to customise the light effect to suit your design needs. Easy to install with the included EASY-LOCK connector and 60cm cable, this luminaire integrates seamlessly into 12V in-lite systems.

Key Benefits:

  • Dual Up & Down Lighting: Projects light both upwards and downwards to add dimension and accentuate surfaces.

  • Warm High-Quality Illumination: Warm white 3000K light with a high CRI (92) for natural colour rendering.

  • Outdoor-Ready Construction: Durable FCBV-coated housing with IP55 weather resistance for reliable outdoor performance.

  • Easy Installation: Supplied with EASY-LOCK connector, 60 cm cable and mounting fixings for quick setup.

  • Customisable Light Effect: Use SHUTTER and optional lenses to tailor beam width and quality.

IN-LITE ACE Up-Down Outdoor LED Wall Light Specifications

Feature Specification
Brand in-lite
Product ACE Up-Down Dark Grey
Article Number 10301950
Application Outdoor wall lighting (fence, façade, patio, overhang)
Light Source Integrated LED
Voltage 12V low voltage
Power Consumption 6.5W
Net Luminous Flux 355lm
Colour Temperature 3000K (Warm White)
CRI (Colour Rendering Index) 92
Light Direction Upward & downward
Beam Type Direct illumination
IP Rating IP55 (dust & water resistant)
Energy Label G
Efficiency 55lm/W
Cable Length 60cm (with EASY-LOCK)
Dimensions (W × H × D) 64mm × 120mm × 95mm
Housing Colour Dark Grey
Housing Material FCBV-coated outdoor-rated finish
Included in Package EASY-LOCK connector, cable, screws & plugs
Recommended Spacing 2.0m - 2.5 m apart at 1.4m - 1.8m height
Installation Surface wall mount
Warranty 5 Years
Description

IN-LITE ACE Up-Down Outdoor LED Wall Light

The in-lite ACE Up-Down Wall Light is a stylish, low-voltage outdoor wall light that casts beams both upwards and downwards. With its contemporary dark grey finish, this fixture is perfect for modern gardens, patios, pathways and exterior living spaces.

Designed with recessed LED sources to minimise glare, the ACE Up-Down delivers focused illumination that highlights textures and creates depth in your outdoor lighting scheme. Accessories like the SHUTTER and LENS can be added to customise the light effect to suit your design needs. Easy to install with the included EASY-LOCK connector and 60cm cable, this luminaire integrates seamlessly into 12V in-lite systems.

Key Benefits:

  • Dual Up & Down Lighting: Projects light both upwards and downwards to add dimension and accentuate surfaces.

  • Warm High-Quality Illumination: Warm white 3000K light with a high CRI (92) for natural colour rendering.

  • Outdoor-Ready Construction: Durable FCBV-coated housing with IP55 weather resistance for reliable outdoor performance.

  • Easy Installation: Supplied with EASY-LOCK connector, 60 cm cable and mounting fixings for quick setup.

  • Customisable Light Effect: Use SHUTTER and optional lenses to tailor beam width and quality.

IN-LITE ACE Up-Down Outdoor LED Wall Light Specifications

Feature Specification
Brand in-lite
Product ACE Up-Down Dark Grey
Article Number 10301950
Application Outdoor wall lighting (fence, façade, patio, overhang)
Light Source Integrated LED
Voltage 12V low voltage
Power Consumption 6.5W
Net Luminous Flux 355lm
Colour Temperature 3000K (Warm White)
CRI (Colour Rendering Index) 92
Light Direction Upward & downward
Beam Type Direct illumination
IP Rating IP55 (dust & water resistant)
Energy Label G
Efficiency 55lm/W
Cable Length 60cm (with EASY-LOCK)
Dimensions (W × H × D) 64mm × 120mm × 95mm
Housing Colour Dark Grey
Housing Material FCBV-coated outdoor-rated finish
Included in Package EASY-LOCK connector, cable, screws & plugs
Recommended Spacing 2.0m - 2.5 m apart at 1.4m - 1.8m height
Installation Surface wall mount
Warranty 5 Years
Easy Installation

Installing an In-Lite Outdoor Lighting set up is as beginner friendly as it gets, even the most novice DIYer's will have no trouble at all!

The system is designed around low-voltage lighting, which means there’s no complicated wiring or specialist electrical knowledge required. With clear instructions and a plug-and-play design, most components simply click together, making it easy to plan and position your lights exactly where you want them.

Once your layout is decided, installation is quick and tidy. The cables can be discreetly laid just beneath the surface, while the fittings are designed to slot neatly into the ground, walls or decking. Because everything works as a complete system, connecting the transformer and testing the lights is simple and stress-free.

Best of all, an in-lite lighting setup is easy to adjust or expand over time. Whether you want to add extra lights or tweak the layout, the flexible design allows you to make changes without starting from scratch!

Here is a step by step guide on getting your In-Lite lighting arrangement set up:

Step 1: Install the smart hub. This should be done in a sheltered dry place such as in a shed or under a canopy. If this is not possible, then install the transformer in the garden in combination with a smart hub protector.

Step 2: Roll out the inlight low voltage cables to all areas that need to be lit. It doesn't have to be buried deeply. A thin layer of soil is sufficient. Then strip the ends of the cables and simply place them in the smart hub.

Step 3: Place the fixtures in the garden according to your lighting plan.

Step 4: Connect each fixture to the main cable via the easy lock provided, you can easily connect them by twisting it shut. The easy lock is 100% safe and watertight.

Step 5 (Smart Hub Transformer required): download the Inlight app and set the schedules. A separate schedule can be set for every zone. You can choose to have them on at all times, to turn them on and off at specific times, or to switch them on at sunset.
